Queen Elizabeth’s flight deck complete
as final sections are lifted into place

2 October 2013

The flight deck of the first of the Navy’s new carriers is now finished with the last two sections added to HMS Queen Elizabeth. The sponsons, each weighing roughly the same as a Sandown-class minehunter, were carefully inched into place in Rosyth.

At just under 500 tonnes, the final sponsons weigh roughly the same as a Sandown-class minehunter.

The flight deck of the Navy’s future flagship is now complete after two giant sections were fixed into place on HMS Queen Elizabeth.

The mighty Goliath crane lifted the sponsons – the sections protruding from the hull which give an aircraft carrier their unique shape – to join the remainder of ship in its dry dock in Rosyth.

At just under 500 tonnes, the final sponsons weigh roughly the same as a Sandown-class minehunter – although by the standards of the Queen Elizabeth, the segments are relatively small; the larger sections weighed in at more than 10,000 tonnes (heavier than a Type 45 destroyer).

Now physically complete – the special paint to protect it from the rigours of the weather and blasts from the F35 Lightning II jets which will land and take off from it – the flight deck is the size of 60 tennis courts (and just a bit smaller than three football pitches).

For those F35 operations (trials are due to begin with the successor jump jet in 2018), a ski ramp will be installed next month – mirroring the feature which propelled the Harrier skywards on the Invincible class of carriers.

The Queen Elizabeth-class project is probably at the peak of effort right now with around 10,000 people involved in building the two leviathans, or providing equipment and systems to be installed on them.

While almost all the media attention is focused on the future flagship, there’s also an all-out effort across the land to build her younger sister Prince of Wales, which is around two years behind Queen Elizabeth.

Sections of three quarters of the Prince’s hull are under construction in Portsmouth, Govan, Merseyside and Tyneside.

Royal Navy press release
